Steering Gear Box HINO EF750/EM100
HINO EF750/EM100
- OEM REF.：
- 480322 Single-a×le
- EF750
- EM100
- CNA NO.：
- CNA-C111-3411010 RH
请选择规格
- Quantity：
Stock：0 pcs Sold：0 pcs
-
Steering Gear Box HINO EF750/EM1000 US$
Total：0 US$
Applicable Front A×le Load 7000kg
Power Cylinder Diameter 100mm
Rated Work Pressure 13MPa
Recommend Pump Flow Rate 16L/min
Circles 6.4r
Output Angle ±47.5°
Oil Inlet Hole M18×1.5
Oil Outlet Hole M18×1.5
Input Shaft Spline Φ21.775×36
Output Shaft Spline Φ55.5×36
| information | |
|---|---|
| CNA NO. | CNA-C111-3411010 RH |
| OEM REF. | 480322 Single-a×le/EF750/EM100 |
| Applicable Front A×le Load | 7000kg |
| Power Cylinder Diameter | 100mm |
| Rated Work Pressure | 13MPa |
| Recommend Pump Flow Rate | 16L/min |
| Circles | 6.4r |
| Output Angle | ±47.5° |
| Oil Inlet Hole | M18×1.5 |
| Oil Outlet Hole | M18×1.5 |
| Input Shaft Spline | Φ21.775×36 |
| Output Shaft Spline | Φ55.5×36 |
| Suitable for | HINO |
